PC792C 50/40 Amp Automotive Plug-In / PCB Mini ISO Relay
50/40 Amp Automotive Plug-In / PCB Mini ISO Relay
Features
Automotive Plug-In PCB Mini ISO Relay, 50 or 40 Amps Continuous Carrying Current, 1A 1C and 1U Contact Forms, Plug In or PC Pins, Plastic or Metal Bracket options, Internal Diode or Resistor, Sockets Available
Specification
Contact Rating
50A@14VDC, 40A@14VDC, 25A@28VDC, 20A@28VDC, 2x30A@14VDC, 2x25A@14VDC, 2x15A@28VDC, 2x12.5A@28VDC
Contact Forms
1A, 1C, 1U
Coil Voltage
6VDC, 12VDC, 24VDC
Mounting Methods
PC Pin, Quick Connect
Dimensional Drawing
